Traxxas Maxx WideMaxx 1/10 Brushless RTR 4WD Monster Truck (Yellow) w/TQi 2.4GHz Radio & TSM (TRA89086-4-YLW)


Out of stock

(No reviews yet) Write a Review
Out Of stock

The Traxxas X-Maxx® is a giant that forever changed the face of RC monster trucks. Its radical cutting-edge design, massive size, brutal strength, and unmatched power transformed X-Maxx into the stuff of legends. The 1/10 Traxxas Maxx® expertly packages X-Maxx’s innovative design elements and jaw-dropping strength into a lighter, more compact, even more ferocious beast. Now the newest Maxx is even bigger, with a longer wheelbase, beefier Sledgehammer® tires, and that incredible WideMaxx® stance for even more intense action. Let the fun begin!

WideMaxx stance stretches the wheels out over 1.5 inches (40 mm) wider for even greater stability.

The extended chassis length now accommodates our most powerful batteries, the same 6700mAh 4-cell LiPo batteries used in the X-Maxx.

Taller Sledgehammer tires feature an aggressive open-block tread design that clears away mud and debris for unrivaled traction.

New Features
WideMaxx┬ü® from the Start
Longer chassis accommodates 6700mAh 4-cell LiPo used in the X-Maxx
Sledgehammer® Tires
Six new colors
VXL-4s™ Waterproof Electronic Speed Control
3S–4S LiPo compatible
Built-in cooling fan
Real-time telemetry via Traxxas Link
Machined heat sinks
10-gauge silicone wire
Integrated protection circuits
LED status lights

Velineon® 540XL Brushless Motor
Long format brushless motor
4-pole 2400 kV
5 mm output shaft
Aluminum heat sink
Cooling fan
55+ MPH out of the box using single 4S LiPo battery (sold separately)
60+ MPH with optional gearing and single 4S LiPo battery (sold separately)
Traxxas Stability Management®
Helps prevents spinouts and loss of control
Adjusts from off to 100% assistance from the transmitter

TQi™ 2.4GHz High Output Radio System
Traxxas Link enabled
2.4GHz 5-channel micro receiver (#6533) with fail-safe security and integrated telemetry ports
Automatically stores and loads settings for up to 30 Traxxas Link-enabled models—just switch on and drive, “model selection” is not required
Multi-Function knob
Adjustable steering and throttle percentage (dual rates)
Adjustable steering and throttle sensitivity (exponential)
Telemetry-ready 5-channel micro receiver

Clipless Body Mount System
Quick one-hand installation and removal
Uses pivoting rear latch mechanism
Eliminates body posts and clips
Reinforced for extra protection against tearing

Full-time shaft-driven 4-wheel drive
Torque-Biasing Center Drive™ absorbs shocks and distributes power
17 mm keyed wheel hex with 5 mm nut
Sealed, silicone fluid-filled diffs with large module ring and pinion gears
Splined outdrives attached with external thru-bolt method
Heavy-duty Cush Drive™
Extreme-duty telescoping driveshafts
Splined aluminum center driveshaft

Secure Motor Mounting System
Precision, preset gear mesh adjustments
Motor retention separate from gear mesh
Full-length motor cradle

New Modular Composite Chassis
Extended modular chassis design interlocks with front and rear bulkheads
Absorbs and distributes impact energy
Easy to service and access components
Driveline is sealed in the chassis to keep out dirt and grit

Easy Battery Access
Extended battery tray accepts Traxxas’ largest 6700mAh 4-cell LiPo battery
Battery is protected deep in the chassis
Battery hold-downs pivot for easy access
More secure than conventional retention systems

Tough energy absorbing front and rear bumpers
Lower front and rear skids for impact and abrasion resistance
Integrated nerf bars for side impact resistance
Wheelie bar with integrated carry handle

Heavy-Duty Steering Bell Cranks and Servo Saver
Large-scale high-output steering servo
285oz-in of torque
0.18 sec transit speed
Triangulated mounting system to fully support case
Heavy-duty double-shear bellcranks

WideMaxx® double-shear suspension arms
1.57” (40 mm) wider for improved handling
Tough new composite formula resists impact damage, even in cold weather
Engineered to optimize suspension travel and steering angles
All critical suspension points have double shear strength
Steel pivot balls
4 mm machined pivot balls
C-hub and steering block geometry maximizes steering angle
Fixed, high-strength camber and toe links
Steel upper and lower tie bars
Full contact sealed bearings used in exposed locations

Machined aluminum threaded body
Extra-large bore and capacity
Large-diameter damper shaft
Lower seal cartridge with dual X-rings
Adjustable upper spring retainer
Plastic shock caps with pivot balls
Lower spring perches bolted

Tough 2.8” wheels with keyed 17 mm hex receptor
Sledgehammer® extreme tires for sure-footed traction
1-piece foam inserts
Pre-glued and ready for action
TSM™ rated

Length: 22.50 inches (572mm)
Front Track: 15.95 inches (405mm)
Rear Track: 15.95 inches (405mm)
Ground Clearance (lowest skid): 1.90 inches (49mm)
Ground Clearance (center skid): 2.6 inches (67mm)
Weight: 10.40 lbs (4.7kg)
Height (ride): 9.12 inches (232mm)
Wheelbase: 13.85 inches (352mm)
Shock Length: 4.90 inches (124mm)
Tire Diameter: 5.64 inches (143mm)
Wheel Diameter: 2.8 / 3.6 inches (70 / 92mm)
Speed Control: Velineon VXL-4s
Motor (electric): 540XL (2400 kV)
Transmission: Single-Speed
Overall Drive Ratio: 12.37 (23/50 motor pinion and spur gear)
Differential Type: Sealed, hardened steel bevel, limited slip
Gear Pitch: Module 1.0
Chassis Structure/Material: Composite Modular Tub
Brake Type: Electronic
Drive System: Shaft-driven 4WD
Steering: Double-shear bellcrank
Wheels & Tires: 2.8” wheels, pre-glued Sledgehammer® Tires & foam inserts; 5.6x2.8–3.6
Radio System: 2-Channel, TQi™ 2.4GHz Transmitter with TSM® receiver
Servo: Torque: 285oz-in.
Top Speed: 60+ MPH with 4S LiPo battery and optional gearing (sold separately)
Skill Level: 4
Battery Tray: 186mm L x 48mm W x 43mm H
Required Batteries: 4 “AA” (transmitter)

Maxx, Ready-To-Race® model with Traxxas 540XL brushless motor
VXL-4s waterproof electronic speed control with integrated telemetry
Quick Start Guide
TQi™ 2.4GHz radio system
High quality maintenance tools

Needed To Complete:
LiPo Battery
Traxxas recommends a 4-cell 14.8V Power Cell LiPo battery for maximum performance. A 3-cell 11.1V LiPo battery will operate the vehicle with reduced performance. NiMH batteries are not supported.
LiPo Balance Charger with iD™
Traxxas EZ-Peak Live 4s-capable charger is recommended for easy and fast charging performance (model #2971).
AA Alkaline Batteries
Four AA alkaline batteries for the transmitter.
