Spektrum RC S6250 Digital High Torque Low Profile Servo (High Voltage) (SPMSS6250)

Spektrum RC
$119.99

Out of stock

Part#
SPMSS6250

(No reviews yet) Write a Review
Spektrum RC S6250 Digital High Torque Low Profile Servo (High Voltage) (SPMSS6250)
Out Of stock
  • Write a Review
  • Print

This is the Spektrum RC S6250 Digital High Torque Low Profile Servo (High Voltage).

The latest generation of Spektrum surface servos provides you with the performance you need for any 1/10th to 1/8th scale vehicle application. The S6230 and S6240 offer high-torque or high-speed performance in a more compact size for 1/10th scale crawlers or monster trucks where space is limited. The S6250 HV and S6260 HV are standard size servos for High-Voltage applications up to 8.4V, And the S6280 HV and S6290 HV feature all metal case construction for the ultimate 1/8th scale performance. All these servos feature Spektrum innovations like the removable wire leads that allow for custom lead length and ease of maintenance and all metal servo mounting tabs to keep them in place through the most extreme conditions.

Features:
Removable wire harness with different lengths available
7075 Aluminum hard anodized output shaft/main gear with steel internal gears
Aluminum case for good heat dissipation
Aluminum mounting tabs
NMB dual main bearings
23T output shaft
Waterproof
1-Year Limited Warranty

Specifications:
Connector Wire Length: 7.87 in (200mm)
Bearing: Dual
Bushing Or Bearing: Bearing
Gear Type: Metal
Maximum Servo Torque: 271 oz-in (19.5kg-cm) @ 6V; 339 oz-in (24.4kg-cm) @ 7.4V; 382 oz-in (27.5kg-cm) @ 8.4V
Material: Metal / Plastic
Programmable: No
Servo Size Category: Standard
Product Length: 1.61 in (41mm)
Rotation Range: 120 deg
Part Type: Electronics
Product Application: Surface
Product Height: 1.25 in (31.8mm)
Current Draw Stall: 4900mA @ 6.0V
Servo Operating Voltage: 6.0 - 8.4V (HV)
Servo Type: Digital
Current Draw Idle: 9.8 mA @ 6.0V
Product Width: 0.82 in (20.8mm)
Wire Gauge: 22 AWG
Application: Surface
Product Weight: 2.3 oz (65.2g)
Spline Count: 23 Teeth

Compatible with:
Axial SCX III
Axial SCX10 Pro
Axial RBX10 Ryft
