This is the Sanwa/Airtronics PGS-HR Programmable SSL SXR Mini Servo
Features:
FH5U: SXR(SANWA XTREME RESPONSE) MODE-COMPATIBLE
SSL-COMPATIBLE PROGRAMMABLE SERVO
# Compatible with CODE 10 (M12S, EXZES ZZ, MT-44)
Not Compatible with CODE 5 (M12, EXZES Z, MT-4S, MT-4, MT-S)
PGS SETTING GEAR-COMPATIBLE
Specialized for 1/12 models
LiPo (1 & 2cell) Battery Support
Digital Servo
Coreless Motor
Full metal gear
Programmable Servo to be compatible with SSL & Telemetry at Launch
Setting Adjustment by wireless from Radio
Setting Adjustment to connect Servo with Setting Gear
Regarding Temperature, Current, Voltage and Volume Position on Servo inside, Telemetry-transmission can be passed to Radio.
#Inital Setting on Setting Gear is necessary
Programming Features:
SSL-CH (SSL Channel Setting)
STRETC (Stretcher Adjustment)
BOOST (BOOST Adjustment)
D-Band (Dead Band Adjustment)
MV-MID (Middle Torque Adjustment)
MV-END (Later Torque Adjustment)
BREAK (Break Adjustment)
MV-HOLD (Power Adjustment at whole area)
MV-FRQ (Feeling Adjustment at whole area)
MAX-PW (MAX Duty Adjustment)
Specifications:
Speed:
0.10 sec / 60° (6.0 V)
0.16 sec / 60° (3.7 V)
Dimensions: 27.0 x 21.1 x 30.5 mm
Torque:
5.8 kg?cm (6.0 V)
3.8 kg?cm (3.7 V)
Weight: 24g
