MKS Servos X5 HBL550 Brushless Metal Gear High Torque Digital Servo (High Voltage) (MKS-HBL550)

MKS Servos
$114.99
In Stock
Part#
MKSHBL550
(No reviews yet) Write a Review
MKS Servos X5 HBL550 Brushless Metal Gear High Torque Digital Servo (High Voltage) (MKS-HBL550)
Add to cart
  • Write a Review
  • Print

This is the High Voltage MKS Servos X5 HBL550 Brushless Metal Gear High Torque Digital Servo.



Specifications:
Dead Band: 0.001ms (Default)
Control System: +Pulse Width Control
Working Frequence: 1520μs / 333hz
Operating Voltage: 5 ~ 8.4 Volts
Operating Temperature Range: -10 to + 60 Degree C
Operating Speed (6V): 0.117 sec/60° degrees at no load
Operating Speed (7.4V): 0.094 sec/60° degrees at no load
Operating Speed (8.4V): 0.085 sec/60° degrees at no load
Stall Torque (6V): 402oz/in (29 kg/cm)
Stall Torque (7.4V): 499 oz/in (36 kg/cm)
Stall Torque (8.4V): 527 oz/in (38 kg/cm)
Motor Type: Brushless Motor
Potentiometer Drive: Indirect Drive
Bearing Type: 12x8 mm Double bearings
Gear Type: Alloy gear
Dimensions: 40 x 20 x 38.5 mm
Weight: 79.5 g
