Castle Creations Sidewinder 8th 1/8 Scale Sensorless Brushless ESC (CSE010-0139-10)

Castle Creations

was $134.99

$102.99
(You save $32.00)

Out of stock

Part#
CSE010013910
(No reviews yet) Write a Review
Castle Creations Sidewinder 8th 1/8 Scale Sensorless Brushless ESC (CSE010-0139-10)
Out Of stock
  • Write a Review
  • Print

Sidewinder 8th is our sport 1:8 scale waterproof* ESC that we have paired with the 1515B-2200Kv - until now! It’s perfect for entry level, weekend basher, or serious road warriors seeking the benefits of an affordable brushless upgrade.Capable of 2-6S LiPo, with an 8 amp peak BEC the Sidewinder 8 is the perfect upgrade for 1:8 scale buggies, truggies and on-road vehicles as well as 1:10 scale monster trucks weighing up to 11 lbs. It can also work as a great upgrade for some 4WD short course trucks for 3s or 4s operation.

Features:
2s - 6s LiPo (25.2V) use in vehicles up 11.lbs. with battery, ready-to-run.
Sensorless motor operation.
Waterproof design ESC and splash resistant 30MM fan*
Powerful 5.5 volts fixed, 8 amps Peak BEC
LED error codes for common error conditions
Smooth sensorless startups
Convenient transmitter programming for nine common adjustable settings
Full compatible with the Castle Link Programming Suite to modify settings and download software updates available via Windows®-based Castle Link software and USB adapter (purchased separately), Field Link Card (sold separately), or the Castle Link iOS App and a B-Link Bluetooth Adapter. (sold separately)

Technical Specs:
ESC:
Input Voltage Range: MIN: 2S LiPo MAX: 6S LiPo (25.2V)
BEC Specifications: 5.5V fixed, 8A peak
Operating Environment: Waterproof* design allows for use in nearly any environment.
Brake: Proportional
Reversible: Yes, but may be disabled for racing.
On/Off Switch: No
Cooling Fan: Yes, factory equipped (30mm), fully removable
Size: 2.45x2.20x1.33" (62.2x56x34mm)
Weight (with wires): 3.52 oz. (100g)
Connectors: 6.5mm female bullets for motor connection.
Items Needed for Operation: Battery Connector required; Deans Ultra Plugs, Traxxas Power Connectors, E-Flite EC5, or 6.5mm Castle Connectors are recommended.
Application Guidelines: Intended for up to 6S (25.2 Volt) operation in vehicles weighing less than 11 lbs, with batteries, ready-to-run.
Recommended Motors: Castle 15xx series motors, 1415-2400kv (Bullet connector change from 4mm to 6.5mm required)
Max Weight: Up to 11 lbs, with batteries, ready-to-run with batteries
Programmability: Fully programmable Castle feature set using Castle Link USB adapter (coupon for free Link included) and freely downloadable Castle Link Windows software, or the Castle Link iOS App and a B-Link Bluetooth Adapter (sold separately).
Telemetry Link Capable: No



Includes:
Sidewinder 8 ESC
User Guide and Quick Start Guide
Castle decals
